| ASTM A135 (BLACK & GALVANISED) SCH10 |
| N.D. |
O.D. |
WALL THICKNESS |
NOMINAL WEIGHT |
TEST PRESSURE |
| inch |
mm |
mm |
kg/m |
Mp |
| 4/3 |
26.8 |
2.11 |
1.28 |
17.24 |
| 1 |
33.5 |
2.77 |
2.09 |
17.24 |
| 1-1/4 |
42.2 |
2.77 |
2.7 |
16.55 |
| 1-1/2 |
48.3 |
2.77 |
3.1 |
14.48 |
| 2 |
60.3 |
2.77 |
3.93 |
11.72 |
| 2-1/2 |
73 |
3.05 |
5.26 |
10.34 |
| 3 |
88.9 |
3.05 |
6.45 |
8.27 |
| 3-1/2 |
101.6 |
3.05 |
7.41 |
6.89 |
| 4 |
114.3 |
3.05 |
8.36 |
6.21 |
| 5 |
141.3 |
3.40 |
11.58 |
5.86 |
| 6 |
168.3 |
3.40 |
13.84 |
5.02 |
| 8 |
219 |
4.80 |
15.41 |
4.26 |
| ASTM A135 (BLACK & GALVANISED) SCH40 |
| N.D. |
O.D. |
WALL THICKNESS |
NOMINAL WEIGHT |
TEST PRESSURE |
| inch |
mm |
mm |
kg/m |
Mp |
| 1/2 |
21.3 |
2.77 |
1.27 |
17.20 |
| 3/4 |
26.8 |
2.87 |
1.68 |
17.20 |
| 1 |
33.5 |
3.38 |
2.50 |
17.20 |
| 1-1/4 |
42.2 |
3.56 |
3.38 |
17.20 |
| 1-1/2 |
48.3 |
3.68 |
4.05 |
17.20 |
| 2 |
60.3 |
3.91 |
5.43 |
16.08 |
| 1-1/2 |
73 |
5.16 |
8.62 |
17.20 |
| 3 |
88.9 |
5.49 |
11.28 |
15.30 |
| 3-1/2 |
101.6 |
5.74 |
13.56 |
14.00 |
| 4 |
114.3 |
6.02 |
16.06 |
13.06 |
| 5 |
141.3 |
6.55 |
21.76 |
11.50 |
| 6 |
168.3 |
7.11 |
28.34 |
10.48 |
| 8 |
219.1 |
8.18 |
36.90 |
7.96 |
ASTM A795 (BLACK & GALVANISED)
N.D. O.D. SCH 10 SCH 30/40
WALL THICKNESS NOMINAL WEIGHT WALL THICKNESS NOMINAL WEIGHT
(mm) (inch) (mm) (inch) (mm) (inch) (kg/mtrs) (lbs/ft) (mm) (inch) (kg/mtrs) (lbs/ft)
15 1/2 21.30 0.84 ---- ---- ---- ---- 2.77 0.109 1.27 0.85
20 3/4 26.70 1.05 2.11 0.083 1.28 0.96 2.87 0.113 1.69 1.13
25 1 33.40 1.32 2.77 0.109 2.09 1.41 3.38 0.133 2.50 1.68
32 1-1/4 42.20 1.66 2.77 0.109 2.69 1.81 3.56 0.14 3.39 2.27
40 1-1/2 48.30 1.90 2.77 0.109 3.11 2.09 3.68 0.145 4.05 2.72
50 2 60.30 2.38 2.77 0.109 3.93 2.64 3.91 0.154 5.45 3.66
65 2-1/2 73.00 2.88 3.05 0.12 5.26 3.53 5.16 0.203 8.64 5.80
80 3 88.90 3.50 3.05 0.12 6.46 4.34 5.49 0.216 11.29 7.58
90 3-1/2 101.60 4.00 3.05 0.12 7.41 4.98 5.74 0.226 13.58 9.12
100 4 114.30 4.50 3.05 0.12 8.37 5.62 6.02 0.237 16.09 10.80
125 5 141.30 5.56 3.4 0.134 11.58 7.78 6.55 0.258 21.79 14.63
150 6 168.30 6.63 3.4 0.134 13.85 9.30 7.11 0.28 28.29 18.99
200 8 219.10 8.63 4.78 0.188 25.26 16.96 7.04 0.277 36.82 24.72
250 10 273.10 10.75 4.78 0.188 31.62 21.23 7.08 0.307 51.05 34.27
