    Product Details:

    Place of Origin: China
    Brand Name: Torich
    Certification: EN10204 3.1
    Model Number: ASTM B161

    Payment & Shipping Terms:

    Price: NEGOTIATION
    Packaging Details: IN WOODEN BOX
    Delivery Time: 45-60 DAYS
    Payment Terms: T/T L/C
    Supply Ability: 6000 TONS PER YEAR
    Minimum Order Quantity: 1tons
    Contact Now
    Detailed Product Description
    Shape: Round Material: Stainless
    High Light:

    stainless steel tube

    ,

    stainless steel pipe

    ,

    steel tube

    BS6323-8 Seamless and Welded steel tubes for automobile,mechanical and general engineering purposesPart

    8: Specific requirements for longitudinally welded stainless steel tubes

    Dimension: O.D.:6-280mm W.T.:1-30mm L:max12000mm

    Applications: for Auto industry / for machinery use/mechanical and general engineering purposes/construction/pumps technology

    Note: Special steel grade is also available, according to customer request



    Steel Grade and Chemical Compositions:

    Mechanical properties

    Designation

    BS 1449-2:
    equivalent

    KM (as welded)

    GKM(S),GZF(S)(welded and sized fully softened)

    GBK (S),and GZF(S)(cold finished ,fully softened)

    Re min.

    Rm min.

    A min.

    Re min.

    Rm min.

    A min.

    Re min.

    Rm min.

    A min.

    N/mm2

    N/mm2

    %

    N/mm2

    N/mm2

    %

    N/mm2

    N/mm2

    %

    LW 12b



    300

    400

    10

    _

    _

    _

    _

    _

    _

    LW 19b

    409S19

    300

    400

    10

    200

    350

    20

    _

    _

    _

    LW 20

    304S11

    420

    520

    25

    185

    480

    30

    _

    _

    _

    LWCF 20















    185

    480

    30

    LW 21

    304S15

    450

    560

    25

    210

    510

    30

    _

    _

    _

    LWCF 21















    210

    510

    30

    LW 22

    316S13

    420

    520

    25

    185

    480

    30

    _

    _

    _

    LWCF 22















    185

    480

    30

    LW 23

    316S33

    450

    560

    25

    210

    510

    30

    _

    _

    _

    LWCF 23















    210

    510

    30

    LW 24

    321S31

    450

    560

    25

    210

    510

    30

    _

    _

    _

    LWCF 24















    210

    510

    30



    Tolerance on specified cut lengths

    Specified cut length

    Tolerance

    over

    up to and including

    mm

    mm

    mm



    500

    +

    2





    -

    0

    500

    2000

    +

    3





    -

    0

    2000

    5000

    +

    5





    -

    0

    5000

    7000

    +

    10





    -

    0

    7000

    __

    by agreement

    NOTE Closer tolerances may be obtained by agreement between the purchaser and manufacturer.






    Tolerance on diameter of as-welded and sized tube

    Outside diameter

    Tolerance



    over

    Up to and including



    mm

    mm

    mm



    30

    ±0.15

    30

    50

    ±0.18

    50

    70

    ±0.25

    70

    90

    ±0.35



    Tolerance on diameter of fully softened tube

    Diameter to thickness ratioD/a

    Tolerance



    over

    up to and including





    mm

    _

    40

    1.5 times value in Table 2

    40

    60

    Twice the value in Table 2

    60

    _

    2.5 times value in Table 2
