Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service

Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service

    • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
    • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
    • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
    • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
    • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
  • Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service

    Product Details:

    Place of Origin: China
    Brand Name: Torich
    Certification: ISO9001,ISO14001,TS16949
    Model Number: P5,P9,P11,P12,P91

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 TONS
    Price: 1200 USD/TON
    Packaging Details: IN BUNDLES
    Delivery Time: 45-60 DAYS
    Payment Terms: T/T,L/C
    Supply Ability: 50000 TONS PER YEAR
    Contact Now
    Detailed Product Description
    Dimensions: O.D.:6-420mm W.T.:1-50mm Application: Steel Workshop
    Standard: ASTM

    ASTM A335 Seamless ferritic and alloy steel pipe for high temperature service



     Applications: for Boilers,Superheaters,Heat-Exchangers

    Size range: O.D.:6-168mm     W.T.:1-15mm      L: according to customer requirement


      Steel Grade and Chemical Compositions:
    Steel Grade C Mn P S Si Cr Mo
    max max max max max min
    P5 0.15  0.30-0.60 0.025  0.025 0.50 4.00-6.00 0.45-0.65
    P9 0.15  0.30-0.60 0.025  0.025 0.25-1.00 8.00-10.00 0.90-1.10
    P11 0.05-0.15 0.30-0.60 0.025  0.025 0.50-1.00 1.00-1.50 0.44-0.65
    P12 0.05-0.15 0.30-0.61 0.025  0.025 0.50 0.80-1.25 0.44-0.65
    P21 0.05-0.15 0.30-0.60 0.025  0.025 0.50 2.65-3.35 0.80-1.06
    P22 0.05-0.15 0.30-0.60 0.025  0.025 0.50 1.90-2.60 0.87-1.13
    P91 0.08-0.12 0.30-0.60 0.020  0.010  0.20-0.50 8.00-9.50 0.85-1.05
    P92 0.07-0.13 0.30-0.60 0.020  0.010  0.50 8.50-9.50 0.30-0.60



    Steel Grade Tensile Strength Yield Strength Elongation Hardness.Max
    min.ksi [Mpa] min.ksi [Mpa] % Brinell/Vickers Rockwell
    P1, P2 55[380] 30[205] 20
    P12 60[415] 32[220] 20
    P23 74[510] 58[400] 20
    P91 85[585] 60[415] 30 250 HB/265 HV 25 HRC
    P92, P911 90[620] 64[440] 30 250 HB/265 HV 25 HRC
    P122 90[620] 58[400] 30 250 HB/265 HV 25 HRC



    Seamless ferritic and alloy steel pipe for high temperature service    Seamless ferritic and alloy steel pipe for high temperature service



    Seamless ferritic and alloy steel pipe for high temperature service    Steel Tubes ASTM A335 with Ferritic and Alloy steel pipe for high temperature service
