Seamless steel tubes for pressure purposes EN10216-2

Seamless steel tubes for pressure purposes EN10216-2

    • Seamless steel tubes for pressure purposes EN10216-2
    • Seamless steel tubes for pressure purposes EN10216-2
    • Seamless steel tubes for pressure purposes EN10216-2
    • Seamless steel tubes for pressure purposes EN10216-2
    • Seamless steel tubes for pressure purposes EN10216-2
  • Seamless steel tubes for pressure purposes EN10216-2

    Product Details:

    Place of Origin: China
    Brand Name: Torich
    Certification: ISO9001-2000, TS16949,DNV
    Model Number: EN10216-2

    Payment & Shipping Terms:

    Price: NEGOTIATION
    Packaging Details: In Hexagonal Bundles
    Delivery Time: 45-60 days
    Payment Terms: T/T, L/C
    Supply Ability: 60000 tons annual
    Minimum Order Quantity: 5 tons
    Contact Now
    Detailed Product Description
    Application: For Manufacturing Pipelines Of Boilers, Vessel Equipment Shape: Round
    Material: Non-alloy Dimensions: O.D.:6-323mm W.T.:1-30mm L: According To Customer

    Torich International Co.,Ltd focus on Seamless steel pipes,DOM steel pipe,Precision steel tubes.Welcome to email us .



    EN10216-2 Seamless steel tubes for pressure purposes Technical delivery conditions Non-alloy steel tubes with specified elevated temperature properties



    Applications: for manufacturing pipelines of boilers, vessel equipment

    Size range: O.D.:6-323mm W.T.:1-30mm L: according to customer requirement

    Chemical composition

    Steel grade

    C

    Si

    Mn

    P

    S

    Cr

    Mo

    Al

    Steel
    name

    Steel
    number

    max

    max

    max

    max

    max

    max

    max



    195GH

    1.0348

    0.13

    0.35

    0.70

    0.025

    0.020

    0.30

    0.08

    ≥0.020

    P235GH

    1.0254

    0.16

    0.35

    1.20

    0.025

    0.020

    0.30

    0.08

    ≥0.020

    P265GH

    1.0425

    0.20

    0.40

    1.40

    0.025

    0.020

    0.30

    0.08

    ≥0.020

    20MnNb6

    1.0471

    0.22

    0.15-
    0.35

    1.0-
    1.50

    0.025

    0.020

    0.30

    0.08

    ≤0.060

    16Mo3

    1.5415

    0.12-
    0.20

    0.35

    0.40-
    0.90

    0.025

    0.020

    0.30

    0.25-
    0.35

    ≤0.040

    10CrM
    o9-10

    1.7380

    0.08-
    0.14

    0.50

    0.30-
    0.70

    0.025

    0.020

    2.0-
    2.50

    0.90-
    1.10

    ≤0.040

    11CrM
    o9-10

    1.7383

    0.08-
    0.15

    0.50

    0.40-
    0.80

    0.025

    0.020

    2.0-
    2.50

    0.90-
    1.10

    ≤0.040

    25Cr
    Mo4

    1.7218

    0.22-
    0.29

    0.40

    0.60-
    0.90

    0.025

    0.020

    3.0-
    3.30

    0.50-
    0.60

    ≤0.040

    Mechanical properties

    Steel Grade

    Tensile properties

    Tensil

    Elongation

    Steel name

    Steel
    number

    Upper yield strength

    Strength

    A min.%

    ReH min for Wall Thickness

    Rm





    T mm







    T16

    16T40

    40T60







    Mpa

    Mpa

    Mpa

    Mpa

    l

    t

    195GH

    1.0348

    195

    ~

    ~

    320-440

    27

    25

    P235GH

    1.0254

    235

    225

    215

    360-500

    25

    23

    P265GH

    1.0425

    265

    225

    245

    410-570

    23

    21

    20MnNb6

    1.0471

    355

    345

    335

    500-650

    22

    20

    16Mo3

    1.5415

    280

    270

    260

    450-600

    22

    20

    10CrMo9-10

    1.7380

    280

    280

    270

    480-630

    22

    20

    11CrMo9-10

    1.7383

    355

    355

    355

    540-680

    20

    18

    25CrMo4

    1.7218

    345

    345

    345

    540-690

    18

    15




    Seamless steel tubes for pressure purposes EN10216-2           Seamless steel tubes for pressure purposes EN10216-2
