    Product Details:

    Place of Origin: China
    Brand Name: Torich
    Certification: ISO9001 TS16947
    Model Number: EN10305-1

    Payment & Shipping Terms:

    Minimum Order Quantity: 0.5tons
    Price: 2000USD/ton
    Packaging Details: In bundles or in wooden boxes packaging
    Delivery Time: 5-8 week days
    Payment Terms: L/C, T/T
    Supply Ability: 5000tons per year
    Contact Now
    Detailed Product Description
    Material: 1010,1020,1045 Etc Standard: EN10305-1
    Length: 12 M Max OD: 6-121mm
    WT: 0.8-18mm Application: Auto Industry

    Torich SGS BV 1020 1035 1045 High tolerance seamless steel tubes /pipes for automotive components



    Production Standard:

    GB/T3639,ASTM A519,DIN2391,EN10305-1,EN10305-1,Customer's special requirement will be upon discussion





    Size:

    O.D. 6-121mm

    W.T.0.8-18mm





    Material:

    10,20,35,45,4130,4140,St52,45 E355 etc.



    Grade and Chemical Composition ( % )

    Grade C Mn P≤ S≤ Si Cr Mo
    1008 ≤ 0.10 0.30-0.50 0.040 0.050 - - -
    1010 0.08-0.13 0.30-0.60 0.040 0.050 - - -
    1018 0.15-0.20 0.60-0.90 0.040 0.050 - - -
    1020 0.18-0.23 0.30-0.60 0.040 0.050 - - -
    1025 0.22-0.28 0.30-0.60 0.040 0.050 - - -
    1026 0.22-0.28 0.60-0.90 0.040 0.050 - - -
    4130 0.28-0.33 0.40-0.60 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25
    4140 0.38-0.43 0.75-1.00 0.040 0.040 0.15-0.35 0.80-1.10

    0.15-0.25



    Delivery condition:

    Cold drawn/hard +C

    Cold drawn/soft+LC

    Cold drawn and stress released:+SR

    Normalizing:+N

    Annealed:+A



    Mechanical properties

    Grade Condition Tensile Point (Mpa) Yield Point (Mpa) Elongation
    1020 CW ≥ 414 ≥ 483 ≥ 5%
      SR ≥ 345 ≥ 448 ≥ 10%
      A ≥ 193 ≥ 331 ≥ 30%
      N ≥ 234 ≥ 379 ≥ 22%
    1025 CW ≥ 448 ≥ 517 ≥ 5%
      SR ≥ 379 ≥ 483 ≥ 8%
      A ≥ 207 ≥ 365 ≥ 25%
      N ≥ 248 ≥ 379 ≥ 22%
    4130 SR ≥ 586 ≥ 724 ≥ 10%
      A ≥ 379 ≥ 517 ≥ 30%
      N ≥ 414 ≥ 621 ≥ 20%
    4140 SR ≥ 689 ≥ 855 ≥ 10%
      A ≥ 414 ≥ 552 ≥ 25%
      N ≥ 621 ≥ 855 ≥ 20%



    Torich SGS BV  1020 1035 1045 High tolerance seamless steel tubes /pipes for  automotive components Torich SGS BV  1020 1035 1045 High tolerance seamless steel tubes /pipes for  automotive components



    QUALITY CONTROL:
    1. Incoming Raw Material Inspection
    2. Raw Material Segregation to avoid steel grade mix-up
    3. Heating and Hammering End for Cold Drawing
    4. Cold Drawing and Cold Rolling, on line inspection
    5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
    6. Straightening-Cutting to specified length-Finished Measuring Inspection
    7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
    8. Packing and Stocking


    100% of our steel tubes are dimensionally checked
    100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
    100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
